Ocular IQ Dual Commercial | 7/22kW x 2 | Socket
The Ocular Dual AC Commercial Wallbox is a high-quality EV charging solution designed to provide reliable Mode 3 AC charging (7kW single-phase or 22kW three-phase) for electric vehicles.
With OCPP 1.6J and OCPP 2.0.1 compatibility, the charger can integrate with charging management systems for remote monitoring, control, and smart charging.
- Billing Capable via OCPP
- 7″ Display Screen
- OCPP 1.6J & OCPP 2.0.1
- Compatible with all-electric vehicles and models including Audi, BMW, BYD, Deepal, EQC, Geely, Holden, Honda, Hyundai, Jaguar, KIA, Mazda, Mercedes Benz, Mini, MG, Mitsubishi, Nissan, Polestar, Porsche, Renault, Rivian, Tesla, Toyota, Volkswagen, Volvo, Xpeng, Zeekr, etc. If you are unsure if this charging station is right for your EV, get in touch with our team.
Technical Specifications:
| Power Output | : | 7kW (1-Phase) per port / 22kW (3-Phase) per port |
| EV Charging Connector | : | Type-2 Socket |
| Input and Output Voltage | : | 230V ± 20% / 400V ± 20% |
| Input and Output Current | : | 32A max per phase per port |
| Frequency (Hz) | : | 50/60Hz |
| Display | : | 7" LCD Touch Screen + LED indication lights |
| Charger Control Method | : | Mobile app, physical button, RFID (ISO14443), plug and charge |
| Internal RCD | : | 30mA AC & 6mA DC leakage protection |
| Electrical Protection | : | Over current, Short circuit, Over voltage, Under voltage, Ground fault, Lightning surge, Over temperature |
| OCPP | : | 1.6J and 2.0.1 (Firmware upgrade required) |
| Internet Connection | : | Ethernet, Wi-Fi, 4G (Nano size sim) |
| Communication Type | : | Modbus (TCP/IP) |
| Energy Meter | : | 2 x MID Meter, Optional NMI Pattern Approved |
| Load Control | : | Compatible with Ocular Load Controller or OCPP smart profiles |
| Ambient Air Temperature for Operation | : | -30°C to +50°C in operation |
| Ambient Air Temperature for Storage | : | -40°C to +70°C in storage |
| Working Humidity | : | 5% - 95% relative humidity, non-condensing |
| Material | : | Powder Coated Stainless Steel |
| Protection Rating | : | IP55, IK10 |
| Mounting | : | Wall Mount |
| Dimension (H x W x D, mm) | : | 550 x 320 x 177 mm |
| Net Weight | : | 18.5 kg |
| Certification | : | CE, IEC /EN 61851-1, IEC/EN 61851-21-2, IEC 62196-2, RCM |
| Warranty | : | 2 Years (Extended warranties available) |
